Features

• Can produce up to 6,000 tests per hour
• Dispense 1 to 16 different reagents simultaneously
• Dispense rate set digitally from 0.01µL/mm to 50µL/mm
• Dispense speed set digitally from 10 to 300mm/second
• Dispense onto membranes up to 500mm long and 120mm wide
• Internal vacuum source to hold down membrane. No external air or vacuum required (except for the atomizing nozzle)
• Dimensions
– 29 cm (11.5”) tall
– 66 cm (26”) long
– 32cm (12.5”) wide
– Weight 13kg (28lbs.)
• Power 150 watts – 110/220 VAC, 50/60 Hz
