SHS-6000 6-Line Auto Dispensing & Sealing System
SHS-6000 is an automated system machine that fills liquid material such as buffer solution into tube and seals using a film and cut the film automatically
Features
• Efficient quality control through prevention from contamination that may occur by contact with human
• Easy setting and operation by Touch Screen
• Stable operation by adopting Servo Motor
• Long-term cost efficiency by minimal labor input
• Vision Inspection
Specification
Model Name: SHS-6000
Applicable products: Liquid Fluid, tube and film
Capacity: 100 EA per a min.
Filling volume: Adjustable (can be customized)
Required manpower: 1 Person
Tube supply: Automatic by elevator conveyor and linear feeder
Main operation: Servo motors
Power Supply: AC 220V, 50/60 Hz
Air consumption: 650L/Min
Control / Panel: PLC/Touch Screen
Required air pressure: 6~7 Kgf/cm² (6~7 Bar)
Dimension: About 2,300(W) x 2,350(L) x 1,050(H) mm
Gross Weight: About 2,000 Kg
